Horizontal Plate Clamp
The horizontal plate clamp is designed by DOHO® for lifting heavy objects for various purposes to save manpower and time. It is manufactured from the best grade of steel material, which provides great strength to perform more reliable operations.
Send Inquiry
Product Description
The horizontal plate clamp has excellent corrosion resistance and extreme weather adaptability, and it is easy to install, which is ideal for improving construction efficiency.The main types of horizontal plate clamps are the PDB Horizontal Plate Clamp and L Horizontal Plate Clamp.
Product features
1.Suitable for lifting and transport of steel plates,construction and profiled bar in horizontal position.
2.Manufactured from high quality carbon steel.
3.Avoid snatch or shock loading.
4.The working load limit is the maximum load that the clamp are authorized to support when used in pairs with a lift angle of 60°.In lifting operations the clamps can be used in pairs or multiples.
5.For the L horizontal plate clamp,the main body and parts are made from die-forge special alloy stells,which are optimally tempered for maximum strength and durbility.
Parameter
PDB Horizontal Plate Clamp
WLL(tonnes)
Jaw Opening(mm)
Weight(kg)
L Horizontal Plate Clamp
Part NO.
Model
SY-0057
PDB1
1
0-30
3.5
SY-0058
PDB2
2
0-40
5.0
SY-0059
PDB3.2
3.2
0-45
6
SY-0060
PDB5
5
0-50
8
SY-0061
PDB8
8
0-100
22
SY-0062
PDB10
10
0-125
33
SY-0063
PDB16
16
0-150
50
SY-0064
PDB30
30
60-270
108
Part NO.
Model
WLL(tonnes)
Jaw Opening(mm)
Weight(kg)
SY-0038
L0.8
0.8
0-15
1.9
SY-0039
L1
1
0-20
3.6
SY-0040
L1.6
1.6
0-25
7
SY-0041
L2.5
2.5
0-30
11
SY-0042
L3.2
3.2
0-40
11
SY-0043
L5
5
0-50
17
SY-0044
L10
10
20-100
43
Application field:
● Steel, non-ferrous metal processing industry
● Wood processing and furniture manufacturing
● Production and transportation of glass products
● Heavy cargo handling in warehouse logistics center
● Automotive manufacturing, aerospace and other high-end manufacturing parts handling
The horizontal plate clips produced by Shengyu provide efficient, stable and safe material handling solutions for modern engineering projects. If you have problems with handling or lifting work, please feel free to contact us.
